| Body | Dimensions | 150.9 x 72.6 x 7.7 mm (5.94 x 2.86 x 0.30 in) |
|---|---|---|
| Weight | 157 g (5.54 oz) | |
| Build | Glass front (Gorilla Glass 4), glass back (Gorilla Glass 4), aluminum frame | |
| SIM | · Nano-SIM (G935F, G935W8) · Nano-SIM + Nano-SIM (G935FD) | |
| IP68 dust tight and water resistant (immersible up to 1.5m for 30 min) |
| Display | Type | Super AMOLED |
|---|---|---|
| Size | 5.5 inches, 83.4 cm2 (~76.1% screen-to-body ratio) | |
| Resolution | 1440 x 2560 pixels, 16:9 ratio (~534 ppi density) | |
| Protection | Corning Gorilla Glass 4 |
| Platform | OS | Android 6.0 (Marshmallow), upgradable to Android 8.0 (Oreo), TouchWiz UI |
|---|---|---|
| Chipset | Qualcomm MSM8996 Snapdragon 820 (14 nm) - G9350 Exynos 8890 Octa (14 nm) - G935FD, G935F, G935W8 | |
| CPU | Quad-core (2x2.15 GHz Kryo & 2x1.6 GHz Kryo) - G9350 Octa-core (4x2.3 GHz Mongoose & 4x1.6 GHz Cortex-A53) - G935FD, G935F, G935W8 | |
| GPU | Adreno 530 - G9350 Mali-T880 MP12 - G935FD, G935F, G935W8 |
| Memory | Card slot | microSDXC (uses shared SIM slot) - dual SIM model only |
|---|---|---|
| Internal | 32GB 4GB RAM, 128GB 4GB RAM | |
| UFS 2.0 |
| Main Camera | Single | 12 MP, f/1.7, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS |
|---|---|---|
| Features | LED flash, auto-HDR, panorama | |
| Video | 4K@30fps, 1080p@30fps (gyro-EIS), 1080p@60fps, 720p@240fps, HDR, stereo sound rec., OIS |
| Selfie camera | Single | 5 MP, f/1.7, 22mm (wide), 1/4.1", 1.34µm |
|---|---|---|
| Features | HDR | |
| Video |
| Sound | Loudspeaker | Yes |
|---|---|---|
| 3.5mm jack | Yes | |
| 24-bit/192kHz audio |
| Comms | WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct |
|---|---|---|
| Bluetooth | 4.2, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS, BDS | |
| NFC | Yes | |
| Radio | No | |
| USB | microUSB 2.0, OTG |
| Features | Sensors | Fingerprint (front-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
|---|---|---|
| ANT+ S-Voice natural language commands and dictation Samsung Pay (Visa, MasterCard certified) |
| Battery | Type | Li-Ion 3600 mAh, non-removable |
|---|---|---|
| Charging | 15W wired, QC2 Wireless (Qi) (market dependent) | |
| Talk time | Up to 27 h (3G) | |
| Music play | Up to 74 h |
| Misc | Colors | Black, White, Gold, Silver, Pink Gold, Black Pearl, Coral Blue |
|---|---|---|
| Models | SM-G935F, SM-G935FD, SM-G935W8, SM-G9350, SM-G935S, SC-02H, SM-G935K, SM-G935L, SM-G935R4, SCV33, SM-G935X, SM-G935VC, SM-G935D | |
| SAR | 0.56 W/kg (head) 0.66 W/kg (body) | |
| SAR EU | 0.26 W/kg (head) 1.43 W/kg (body) |
