| Launch | Announced | 2017, March 29. Released 2017, April 24 |
|---|---|---|
| Status | Discontinued |
| Body | Dimensions | 148.9 x 68.1 x 8 mm (5.86 x 2.68 x 0.31 in) |
|---|---|---|
| Weight | 155 g (5.47 oz) | |
| Build | Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame | |
| SIM | Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by) | |
| IP68 dust/water resistant (up to 1.5m for 30 min) |
| Display | Type | Super AMOLED, HDR10 |
|---|---|---|
| Size | 5.8 inches, 84.8 cm2 (~83.6% screen-to-body ratio) | |
| Resolution | 1440 x 2960 pixels, 18.5:9 ratio (~570 ppi density) | |
| Protection | Corning Gorilla Glass 5 | |
| 3D Touch (home button only) Always-on display |
| Platform | OS | Android 9.0 (Nougat), upgradable to Android 9.0 (Pie), One UI |
|---|---|---|
| Chipset | Exynos 8895 (10 nm) - EMEA Qualcomm MSM8998 Snapdragon 835 (10 nm) - USA & China |
|
| CPU | Octa-core (4x2.3 GHz Mongoose M2 & 4x1.7 GHz Cortex-A53) - EMEA Octa-core (4x2.35 GHz Kryo & 4x1.9 GHz Kryo) - USA & China |
|
| GPU | Mali-G71 MP20 - EMEA Adreno 540 - USA & China |
| Memory | Card slot | microSDXC (uses shared SIM slot) - dual SIM model only |
|---|---|---|
| Internal | 128GB 6GB RAM | |
| UFS 2.0 or UFS 2.1 |
| Main Camera | Single | 12 MP, f/1.7, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS |
|---|---|---|
| Features | LED flash, auto-HDR, panorama | |
| Video | 4K@30fps, 1080p@30/60fps, 720p@240fps, HDR, stereo sound rec., gyro-EIS, OIS |
| Selfie camera | Dual | 8 MP, f/1.7, 25mm (wide), 1/3.6", 1.22µm, AF 2 MP (dedicated iris scanner camera) |
|---|---|---|
| Features | HDR | |
| Video | 1440p@30fps |
| Sound | Loudspeaker | Yes |
|---|---|---|
| 3.5mm jack | Yes | |
| 32-bit/384kHz audio |
| Comms | WLAN | Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct |
|---|---|---|
| Bluetooth | 5.0, A2DP, LE, aptX | |
| Positioning | GPS, GLONASS, BDS, GALILEO | |
| NFC | Yes | |
| Radio | No | |
| USB | USB Type-C 3.1 |
| Features | Sensors | Iris scanner, fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2 |
|---|---|---|
| Samsung DeX (desktop experience support) ANT+ Bixby natural language commands and dictation Samsung Pay (Visa, MasterCard certified) |
| Battery | Type | Li-Ion 3500 mAh, non-removable (11.55 Wh) |
|---|---|---|
| Charging | 15W wired, QC2 Wireless (Qi/PMA) (market dependent) |
|
| Talk time | Up to 20 h (3G) | |
| Music play | Up to 67 h |
| Misc | Colors | Midnight Black, Orchid Gray, Arctic Silver, Coral Blue, Maple Gold, Rose Pink, Burgundy Red |
|---|---|---|
| Models | SM-G950FD, SM-G950W, SM-G950S, SM-G950K, SM-G950L, SM-G9500, SM-G950A, SM-G950P, SM-G950T, SM-G950U, SM-G950V, SM-G950F, SM-G950U1, SM-G950N, SC-02J, SCV36, SM-G950, G950F | |
| SAR | 0.44 W/kg (head) 0.75 W/kg (body) | |
| SAR EU | 0.32 W/kg (head) 1.27 W/kg (body) | |
| Tests | Performance | AnTuTu: 199022 (v7) GeekBench: 6656 (v4.4) GFXBench: 13fps (ES 3.1 onscreen) |
|---|---|---|
| Display | Contrast ratio: Infinite (nominal), 4.768 (sunlight) | |
| Camera | Photo / Video | |
| Loudspeaker | Voice 66dB / Noise 70dB / Ring 72dB | |
| Audio quality | Noise -92.5dB / Crosstalk -92.8dB | |
| Battery (old) |
Endurance rating 84h
|
